Holds utilities to work with register caches. More...
Go to the source code of this file.
Functions | |
| void | register_cache_invalidate (struct reg_cache *cache) |
| Marks the contents of the register cache as invalid (and clean). More... | |
| struct reg * | register_get_by_name (struct reg_cache *first, const char *name, bool search_all) |
| struct reg * | register_get_by_number (struct reg_cache *first, uint32_t reg_num, bool search_all) |
| static int | register_get_dummy_core_reg (struct reg *reg) |
| struct reg_cache ** | register_get_last_cache_p (struct reg_cache **first) |
| void | register_init_dummy (struct reg *reg) |
| static int | register_set_dummy_core_reg (struct reg *reg, uint8_t *buf) |
| void | register_unlink_cache (struct reg_cache **cache_p, const struct reg_cache *cache) |
Variables | |
| static const struct reg_arch_type | dummy_type |
Detailed Description
Holds utilities to work with register caches.
OpenOCD uses machine registers internally, and exposes them by name to Tcl scripts. Sets of related registers are grouped into caches. For example, a CPU core will expose a set of registers, and there may be separate registers associated with debug or trace modules.
Definition in file register.c.
Function Documentation
◆ register_cache_invalidate()
| void register_cache_invalidate | ( | struct reg_cache * | cache | ) |
Marks the contents of the register cache as invalid (and clean).
Definition at line 94 of file register.c.
References reg::dirty, reg::exist, reg_cache::num_regs, reg_cache::reg_list, and reg::valid.
Referenced by aarch64_assert_reset(), aarch64_restore_context(), adapter_resume(), adapter_step(), arc_assert_reset(), arc_resume(), arc_step(), arm11_assert_reset(), arm11_debug_entry(), arm11_leave_debug_state(), arm7_9_assert_reset(), arm7_9_resume(), arm7_9_soft_reset_halt(), arm7_9_step(), avr32_ap7k_resume(), cortex_a_assert_reset(), cortex_a_internal_restart(), cortex_a_internal_restore(), cortex_m_assert_reset(), cortex_m_endreset_event(), cortex_m_poll(), cortex_m_resume(), cortex_m_soft_reset_halt(), cortex_m_step(), dsp563xx_assert_reset(), dsp563xx_resume(), dsp563xx_step_ex(), esirisc_assert_reset(), esirisc_resume_or_step(), execute_resume(), hl_assert_reset(), mips_m4k_assert_reset(), mips_m4k_internal_restore(), mips_m4k_step(), nds32_assert_reset(), nds32_poll(), nds32_profiling(), nds32_v2_debug_entry(), nds32_v2_leave_debug_state(), nds32_v3_debug_entry(), or1k_resume_or_step(), resume_finish(), riscv_invalidate_register_cache(), riscv_openocd_step(), stm8_reset_assert(), stm8_resume(), stm8_step(), xscale_deassert_reset(), xscale_resume(), xscale_step_inner(), and xtensa_assert_reset().
◆ register_get_by_name()
Definition at line 50 of file register.c.
References reg::exist, name, reg::name, reg_cache::next, NULL, reg_cache::num_regs, and reg_cache::reg_list.
Referenced by armv4_5_run_algorithm_inner(), armv7m_start_algorithm(), armv7m_wait_algorithm(), COMMAND_HANDLER(), dsp563xx_run_algorithm(), mips32_run_algorithm(), nds32_arch_state(), riscv_run_algorithm(), stm8_run_algorithm(), target_jim_get_reg(), target_jim_set_reg(), and target_profiling_default().
◆ register_get_by_number()
Definition at line 28 of file register.c.
References reg::exist, reg_cache::next, NULL, reg_cache::num_regs, reg::number, and reg_cache::reg_list.
Referenced by hwthread_get_thread_reg(), and hwthread_set_reg().
◆ register_get_dummy_core_reg()
|
static |
Definition at line 106 of file register.c.
References ERROR_OK.
◆ register_get_last_cache_p()
Definition at line 72 of file register.c.
Referenced by arc_build_bcr_reg_cache(), arc_build_reg_cache(), arm11_examine(), arm7_9_examine(), arm7tdmi_build_reg_cache(), arm9tdmi_build_reg_cache(), arm_dpm_setup(), armv7m_build_reg_cache(), armv8_build_reg_cache(), avr32_build_reg_cache(), cortex_m_dwt_setup(), dsp563xx_build_reg_cache(), esirisc_build_reg_cache(), lakemont_build_reg_cache(), mips32_build_reg_cache(), mips64_build_reg_cache(), nds32_reg_cache_init(), or1k_build_reg_cache(), stm8_build_reg_cache(), xscale_build_reg_cache(), and xtensa_build_reg_cache().
◆ register_init_dummy()
| void register_init_dummy | ( | struct reg * | reg | ) |
Definition at line 124 of file register.c.
References dummy_type, and reg::type.
Referenced by mips32_build_reg_cache().
◆ register_set_dummy_core_reg()
|
static |
Definition at line 111 of file register.c.
◆ register_unlink_cache()
Definition at line 85 of file register.c.
References reg_cache::next.
Referenced by cortex_m_dwt_free(), and xtensa_free_reg_cache().
Variable Documentation
◆ dummy_type
|
static |
Definition at line 111 of file register.c.
Referenced by register_init_dummy().
