The arm_nand_data struct is used for defining NAND I/O operations on an ARM core. More...
Data Fields | |
| unsigned | chunk_size |
| The chunk size is the page size or ECC chunk. More... | |
| struct working_area * | copy_area |
| The copy area holds code loop and data for I/O operations. More... | |
| uint32_t | data |
| Where data is read from or written to. More... | |
| enum arm_nand_op | op |
| Last operation executed using this struct. More... | |
| struct target * | target |
| Target is proxy for some ARM core. More... | |
Detailed Description
The arm_nand_data struct is used for defining NAND I/O operations on an ARM core.
Field Documentation
◆ chunk_size
| unsigned arm_nand_data::chunk_size |
The chunk size is the page size or ECC chunk.
Definition at line 30 of file arm_io.h.
Referenced by arm_nandread(), arm_nandwrite(), at91sam9_read_block_data(), at91sam9_write_block_data(), nuc910_nand_read_block_data(), nuc910_nand_write_block_data(), and orion_nand_fast_block_write().
◆ copy_area
| struct working_area* arm_nand_data::copy_area |
The copy area holds code loop and data for I/O operations.
Definition at line 27 of file arm_io.h.
Referenced by arm_nandread(), and arm_nandwrite().
◆ data
| uint32_t arm_nand_data::data |
Where data is read from or written to.
Definition at line 33 of file arm_io.h.
Referenced by arm_nandread(), arm_nandwrite(), at91sam9_read_block_data(), at91sam9_write_block_data(), and NAND_DEVICE_COMMAND_HANDLER().
◆ op
| enum arm_nand_op arm_nand_data::op |
Last operation executed using this struct.
Definition at line 33 of file arm_io.h.
Referenced by arm_nandread(), arm_nandwrite(), and NAND_DEVICE_COMMAND_HANDLER().
◆ target
| struct target* arm_nand_data::target |
Target is proxy for some ARM core.
Definition at line 24 of file arm_io.h.
Referenced by arm_nandread(), arm_nandwrite(), and NAND_DEVICE_COMMAND_HANDLER().
The documentation for this struct was generated from the following file:
